TSH-02 15 Minutes Quick Install Folding Container House

TSH-02 15 Minutes Quick Install Folding Container House

TSH-02 quick install folding container house is our new design, which can be finished installation in 15 minutes and folded thousands of times.

Item No :
TSH-02
Order(MOQ) :
1
Product Origin :
China
Dimensions :
5830mm*2500mm*2470mm
Frame Structure :
Galvanized steel
Wall Panel :
50mm Thickness Color Steel EPS Sandwich Panel
Roof Load :
100kg/sqm
Floor :
Cement fiber board and glass magnesium board
Window :
Plastic steel window, aluminum alloy window
Door :
Aluminum alloy doors, plastic steel doors, stainless steel doors
Production Capacity :
1000
Loading capacity :
1*40HQ=10 units

Inquiry now

Share to :

Product Details

Quick Install Folding Container House
	Export Model
Product specifications	Folded Height	H=440mm
	Loading capacity	1*40HQ=10 units
	LengthWidthHeight（mm）	5830mm2500mm2470mm
	Roof Form	Flat Roof
	Number Of Layers	≤2 layers
Structure	Column	Specifications=50mm*160mm，Roller beam，Material Thickness=2.3mm，Material=Q235B
	Roof Main Beam	Specifications=50*160mm，Roller beam，Material Thickness=2.3mm，Material=Q235B
	Roof Secondary Beam	Galvanized Cold Rolled Section Steel C Type，Material Thickness=1.0mm，6 Pices，Material=Q235B
	Ground Main Beam	Height=50*140mm，Roller beam，Material Thickness=2.3mm，Material=Q235B
	Ground Secondary Beam	Galvanized Cold Rolled Section Steel C Type，Material Thickness=1.5mm，9 Pices，Material=Q235B
	Bolt	8.8 Class High-Strength Bolts, 6
	Paint	Electrostatic spraying plastic powder baking varnish ≥80μm
Roof	Roof Panel	EPS Color Steel Sandwich Panel，Thickness=50mm，Color=White-Gray, Falls freely into the water
Floor	Substrate	18mm Fireproof Glass Magnesium Board
Panel	Insulation Cotton	50mm Thickness Color Steel EPS Sandwich Panel，Class B Fire Protection
Panel	Color steel Plate	Panel Coler Streel Plate Thickness=0.4mm
Door	Specification	WidthHeight=840mm1900mm
Door	Material	Steel Door, Concealed Buckle Lock
Window	Specification	950mm*1100mm
	Fram Material	Plastic Steel
	Glass	Single Glass
Electricity	Voltage	220V，50Hz
	Wire	Concealed Line, Total Home Power Line 34 Square, Air-conditioning line 34 square, Socket Line 32.5 Square, Lighting Switch Line 21.5 Square
	Breaker	High Breaking Miniature Circuit Breaker
	Illumination	1 set of 1200*300 ultra-thin LED lights, power 36W
	Socket	4 Five-hole sockets 10A (or USB socket), 1 Three-hole air conditioner socket 16A, 1 Single switch 10A
Other	Folding hardware	Special Parts, No Hinges
Standardized construction is adopted, and equipment and accessories conforming to national standards are used

Our TSH-02 Folding Container House can be folded more than 100 times

and has long lifespan for more than15 years.

The 15 Minutes Quick Install Folding Container House can be used as

office, home, shopping mall and construction site temporary living room

etc.
